American-style single push button "light" mechanism
![DECO Soft](/media/filer_public/e5/b0/e5b0b665-da18-46e0-a469-afcd3e82a1c5/dwpus-5.jpg)
white
DWPUS-5
Product description
Downloads
Configurator
DECO mechanisms and frames are sold separately.
DECO switches in American style are also available in an illuminated version – a light module shall be bought separately to each switch. Available light modules:
> Incandescent light module: L-1 white.
> Light module LED: L-2 white, 2L-2 green, 3L-2 blue, 17L-2 red.
Light modules can go with all DECO switches besides the following switches: DWPUS-8, DWPUS-33 and DWPUS-10.2.
DECO switches in american style are not available in hermetic type (IP44) - sealant can not be used with the American style switches mechanisms.
Technical data
Protection index | IP 20 |
Rated current | 10 AX |
Rated voltage | 250 V~ |
![Technical image](/media/techdata/soft_dwpus-1.jpg)
